System Manual 4. System Components
76.7300FP11/2, Rev A 8/09 Page 2-39
Small Form-Factor Pluggables (SFPs/XFPs)
4.37 This section describes the features and circuitry of the SFPs and XFPs
supported in the Tellabs 7345 Switch and the Tellabs 7325 Switch.
4.38 The Tellabs 7345 Switch 10G Switch module supports 24 triple-speed
(10/100/1000) SFP-based interfaces and up to two 10 GigE XFP interfaces
depending on the 10G Switch module installed:
• 82.731150A-R5—2 x 10G XFP, 24 x 1G SFP
• 82.731150B-R5—1 x 10G XFP, 24 x 1G SFP
• 82.731150C-R5—0 x 10G XFP, 24 x 1G SFP
4.39 Full line rate throughput is supported for all interfaces operating at 10 GigE
and GigE rates via an on-board Ethernet switch.
4.40 Tellabs recommends using only Tellabs parts to ensure interoperability;
however, the Tellabs 7345 Switch and the Tellabs 7325 Switch support third-party
SFP pluggable optics and the Tellabs 7345 Switch supports third-party XFP
pluggable optics.
SFP/XFP Physical Specifications
4.41 Refer to Table 4.9, page 2-39 for Tellabs 7345 Switch and Tellabs 7325
Switch SFP power specifications.
Table 4.9 Power Specifications of Tellabs 7345 Switch and Tellabs 7325 Switch SFPs
Type Tellabs Part Number Description Tx-Min Tx-Max Rx-Min Rx-Max
GBE 81.S1GBER450010
1
SFP: 10/100/1000 BaseT
RJ-45
n/a n/a n/a n/a
81.S1GBESX1851M
1
SFP: SR/SX, 850 nm, MM -9.5 -4 -15 0
81.S1GBELX1131S
1
SFP: LX, 1310 nm, SM -9.5 -3 -21 0
81.S1GBEZX1151S
1
SFP: ZX, 1550 nm, SM 0 5 -21 0
100Base
FX
81.S125M000132M
2,3
SFP: 125 Mbps, 2 km,
1310 nm, MM
-20 -14 -30 -14
81.S125M000132S
4
SFP: 125 Mbps, 10 km,
1310 nm, SM
-15 -8 -31.5 -8
1. Meets IEEE Standard 802.3.
2. Use only with 62.5 micron multi-mode fiber.
3. Meets IEEE Standard 802.3-2002.
4. Meets IEEE Standard 802.3ah-2004.
