5. Installation System Manual
Page 2-76 8/09 76.7300FP11/2, Rev A
Vendor : Tellabs
Product : Tellabs 73xx
Last SW Update : 2009-07-28 16:05:44
Last System Backup : 0000-00-00 00:00:00
Database Version : CPE1_1_TMP_VERS
Last Database Save : 0000-00-00 00:00:00
Last Remote Backup : 0000-00-00 00:00:00
__ 7. Display the slot/module status by entering the following command:
show hardware
System response:
Line Card Config table
-----------------
SlotId Status Card Name
------ ------ ---------
1 UP FAN
2 UP TGX2
3 -- NotAvailable
4 DOWN UNASSIGNED
5 -- NotAvailable
6 UP PSU
7 UP PSU
8 UP CMCC
9 Inactive
__ 7.1 Verify that the system response matches the hardware
installed.
__ 8. If SFPs/XFPs are installed, connect a fiber/cable between the transmit
and receive interfaces, and verify the port LED is green. For all missing
SFPs/XFPs, the port LED should be off.
If an SFP is installed and the fiber is not connected and the port state
is down, the port LED will be amber. If the port state is up, the port LED
will be red.
The Tellabs 7300 NE should be fully initialized at this point
.
Note: The CLI prompt looks like the following example:
t7300-#
The default prompt is t7300-#. If you configure the system ID, the prompt
will change.
One Power Supply Installed 5.75 Perform the following steps to display the System Power Supply
Redundancy setting (system default is Redundant).
__ 1. Enter the following command to display current system status:
t7300-tlab7300# show system information
System response:
System ID : tlab7300
System Contact : Tellabs Technical
Assistance at 1.800.443.5555
System Location : Tellabs Operations, Inc, USA
System Site : TELLABS
System Configuration : 10G-Switch
System Power Supply Redundancy : Redundant
System Switch Redundancy : Non-Redundant
Logging Option : Console Logging
Login Authentication Mode : Local
Config Save Status : Not Initiated
Remote Save Status : Not Initiated
Config Restore Status : Not Initiated
