Tellabs 7300 Series User Manual

5. Installation System Manual
Page 2-46 8/09 76.7300FP11/2, Rev A
Unpacking the Tellabs 7300 NE Components
5.18 Carefully remove the components from their shipping containers.
Compare the equipment received to the shipping list to verify that all items have
been received. If any items are missing, contact your Tellabs representative. For a
complete list of Tellabs 7345 Switch and Tellabs 7325 Switch components and
accessories, refer to Table 4.1, page 2-25 (Tellabs 7345 Switch), Table 4.6,
page 2-35 (Tellabs 7325 Switch) and Table 5.1, page 2-46.
5.19 After unpacking the components, inspect all equipment to determine if any
shipping damage occurred. Keep containers and packing material in the event
there is damage to the equipment and it needs to be returned. If damage is found,
immediately file a claim. If the equipment has been in storage, reinspect it prior to
installation. Do not install damaged equipment.
Accessories
5.20 Refer to Table 5.1, page 2-46 for Tellabs 7300 NE accessories which can
be purchased through your Tellabs representative.
Warning:
Electrostatic discharge (ESD) may damage sensitive electronic components
resulting in a traffic-affecting condition. Ensure that plug-in modules are stored
in static preventive material. Do not touch any components on the modules.
Handle modules by the edges or front panel. Always wear a properly grounded
wrist strap when handling, removing, or inserting a module and when touching
the equipment shelf or cables. ESD protective flooring, used with proper ESD
footwear, may be used as an alternative to a wrist strap. Check ESD wrist straps
and footwear daily to verify performance.
Warning:
Operating a damaged shelf can harm the shelf and the devices that
interface to it.
Table 5.1 Accessories
Tellabs Part
Number Where Used Part Description
155.0175-00xx 1 GBE Multi-mode LC-SC CBL FO MM 2 FIB 2.0 ZIP SC/LC DUP Family
/62.5/125 um Orange Jacket xx=1–99 meters
155.0403-00xx 1 GBE Multi-mode LC-LC CBL FO MM 2 FIB 2.0 ZIP LC/LC DUP Family
/62.5/125 um Orange Jacket xx=1-99 meters
255-0041-Mxxxx 1 GBE/10GBE Multi-mode
LC-SC
CBL FO MM 2 FIB 2.0 ZIP SC/LC 50 AQUA
FMLY/50/125 um AQUA JACKET xxxx=length in
meters
255-0042-Mxxxx 1 GBE/10GBE Multi-mode
LC-LC
CBL FO MM 2 FIB 2.0 ZIP LCDUP 50 AQUA FMLY
xxxx=length in meters
