4. System Components System Manual
Page 2-40 8/09 76.7300FP11/2, Rev A
4.42 Refer to Table 4.10, page 40 for Tellabs 7345 Switch XFP power
specifications.
4.43 Refer to Table 4.11, page 2-40 for Tellabs 7345 Switch Extended
Temperature (I-TEMP) SFP/XFP power specifications.
Table 4.10 Power Specifications of Tellabs 7345 Switch XFPs
Type
Tellabs Part
Number Description Tx-Min Tx-Max Rx-Min Rx-Max
10GBE 81.X111GSR1131S
1
XFP: SR, 1310 SM -6 -1 -11 1
81.X111GIR2151S
1
XFP: IR-2, 1550 SM -1 +2 -14 -1
81.X111GLR2151S XFP: LR-2, 1550 SM 0 +4 -24 -7
1. Meets IEEE Standard 802.3ae.
Table 4.11 Power Specifications of Tellabs 7345 Switch I-TEMP SFPs/XFPs
Type
Tellabs Part
Number Description Tx-Min Tx-Max Rx-Min Rx-Max
GBE 81.S1GBER450030 SFP: GBE, Electrical, RJ-45,
I-TEMP
n/a n/a n/a n/a
81.S1GBESX1853M SFP: GBE/FC/FICON, SR/SX,
850 MM, I-TEMP
-9.5 -2.5 -17 0
81.S1GBELX1133S SFP: GBE/FC/FICON, LX,
1310 SM, I-TEMP
-9.5 -3 -20.5 -3
81.S1GBEZX1153S SFP: GBE/FC/FICON, ZX,
1550 SM, I-TEMP
05 -24-3
100Base
FX
81.S125M000133M
1
SFP: 100BaseFX (125Mbps) -
2km, 1310 MM, I-TEMP
-20 -14 -31.5 -8
81.S125M000133S SFP: 100BaseFX (125Mbps) -
10km, 1310 SM, I-TEMP
-15 -8 -31.5 -8
10GBE 81.X111GSR1133S
2
XFP: 11.1G, SR, 1310 SM,
I-TEMP
-6 -1 -14.4 1
81.X111GIR2153S
2
XFP: 11.1G, IR-2, 1550 SM,
I-TEMP
-1 2 -16 1
1. Use only with 62.5 micron multi-mode fiber.
2. This XFP is not available for the Tellabs 7325 Switch.
