4. System Components System Manual
Page 2-26 8/09 76.7300FP11/2, Rev A
4.05 All Tellabs 7345 Switch common components are available for individual
ordering.
81.73ETSI-A-R6 21 inch 2RU ETSI Shelf Mounting Adapter Kit
81.73NEBS-A-R6 23 inch 2RU NEBS Shelf Mounting Adapter Kit
81.71020FP5-5-R5 Fuse Panel - 5 fuses per side
60.0332 GMT 2.0A Fuse
60.0273 GMT 3.0A Fuse
60.0088 GMT 5.0A Fuse
163.006 GMT 7.5A Fuse
81.73GND-KIT-R6
2
7300 Universal Grounding Kit
81.73W-25SCA-R5 7300 Serial Port Adapter
81.S1GBER450010 SFP: 10/100/1000 BaseT RJ-45
81.S1GBESX1851M SFP: SR/SX, 850 nm, MM
81.S1GBELX1131S SFP: LX, 1310 nm, SM
81.S1GBEZX1151S SFP: ZX, 1550 nm, SM
81.S125M000132M
4
SFP: 125 Mbps, 2 km, 1310 nm, MM
81.S125M000132S SFP: 125 Mbps, 10 km, 1310 nm, SM
81.X111GSR1131S XFP: SR, 1310 SM
81.X111GIR2151S XFP: IR-2, 1550 SM
81.X111GLR2151S XFP: LR-2, 1550 SM
81.S1GBER450030 SFP: GBE, Electrical, RJ-45, I-TEMP
81.S1GBESX1853M SFP: GBE/FC/FICON, SR/SX, 850 MM, I-TEMP
81.S1GBELX1133S SFP: GBE/FC/FICON, LX, 1310 SM, I-TEMP
81.S1GBEZX1153S SFP: GBE/FC/FICON, ZX, 1550 SM, I-TEMP
81.S125M000133M
4
SFP: 100BaseFX (125Mbps) - 2km, 1310 MM, I-TEMP
81.S125M000133S SFP: 100BaseFX (125Mbps) - 10km, 1310 SM, I-TEMP
81.X111GSR1133S XFP: 11.1G, SR, 1310 SM, I-TEMP
81.X111GIR2153S XFP: 11.1G, IR-2, 1550 SM, I-TEMP
81.SFP-BLK Blank SFP (optional)
1. The 10G Switch modules do not come with the pluggable optics. Order the required SFPs and XFPs at the time you order 10G
Switch modules. The 10G Switch modules do not require that all pluggable optic ports be populated.
2. Replacement or spare parts only.
3. Only required if redundant PSU modules are not ordered.
4. Use only with 62.5 micron multi-mode fiber.
Table 4.1 Available Hardware for Tellabs 7345 Switch
