5. Installation System Manual
Page 2-74 8/09 76.7300FP11/2, Rev A
Table 5.5 Pinout for 250.004x Cable
12 AUX-ALARM3_Out aux8 (Ext Contact Output 8)
13 NC no connect
14 RA_B Rack Alarm MJ Output
15 3.3V pull up (reserved - AUX_VCC)
Table 5.4 Pinout for DB-15 Connector
Pin
Number Signal Name Usage
Connector
Pin Number Jacket Color
1 White/Blue
2Blue/White
3 White/Orange
4 Orange/White
5 White/Green
6 Green/White
7 White/Brown
8Brown/White
9 White/Slate
10 Slate/White
11 Red/Blue
12 Blue/Red
13 Red/Orange
14 Orange/Red
15 Red/Green
Spare Green/Red
To Next Page
