29
Select Scheduler for
Queues of Equal
Precedence
Select the default scheduler for the queues with equal precedence.
Round Robin It assigns different weights for different kinds of packets and
provides the packets with different bandwidths based on the weights.
Weighted Fair Queuing It divides groups into different queues based on the
service streaming, IP precedence, and Hash algorithm, and fairly assigns the
bandwidth to the services with low precedence according to the weights while
ensuring the performance of services with high precedence.
It specifies to set up the weight of the default queue.
It specifies to set up the precedenceof the default queue.
Default Queue Drop
Algorithm
It specifies the default queue drop algorithm. It cannot be changed.
4.1.1.2 Setting up a WAN Service for the ATM Interface
PPPoE
Choose the corresponding procedure to follow according to your IP address type: IPv4 PPPoE,
IPv4&IPv6 PPPoE, and IPv6 PPPoE.
IPv4 PPPoE
Step 1 Choose Advanced Setup > WAN Service to enter the following page, and click Add.
Step 2 Select ATM interface you create on the Layer2 Interface page, which is atm0/(0_0_35) in
this example, and click Next.
