Appendix B RS-232 Commands
B-13
set time
hh:mm:ss
hh = hours
mm = minutes
ss = seconds
Sets the internal clock (military time). The example below sets the internal time to 2:15
pm. Note that if seconds are omitted, the seconds default to 00.
Send: "set time 14:15"
Receive: "set time 14:15 ok"
date
This reports the current date. The example below reports the date as December 1, 1994.
Send: "date"
Receive: "date 12-01-94"
set date
mm-dd-yy
mm = month
dd = day
yy = year
Sets the internal date. The example below sets the internal date to December 1, 1994.
Send: "set date 12-01-94"
Receive: "set date 12-01-94 ok"
agc int
This reports the current intensity of the reference channel AGC circuit. The example
below reports that the current AGC intensity is 250,000 Hz.
Send: "agc int"
Receive: "agc int 250000 Hz"
