Chapter 3 Operation
3-64
Pressure
The Pressure screen, shown below, shows the fluorescence chamber pressure. The
fluorescence chamber pressure is updated every second. This screen is used while
adjusting the pressure transducer potentiometers.
CAUTION:
Some internal components can be damaged by small amounts of static
electricity. A properly grounded antistatic wrist strap must be worn while handling any
internal component. For more information about appropriate safety precautions, see
Chapter 7, “Servicing.”
To display the Pressure screen:
From the Main Menu choose Service Mode
From the Service Mode menu choose Pressure
To use the Pressure screen:
This is a view only screen
Press
MENU
to return to the Service Mode menu
Press
RUN
to return to the Run screen
Pressure Screen
