Chapter 3 Operation
3-46
Option Switches
The Option Switches screen, shown below, enables the settings of the internal option
switches to be viewed. Use the
↑
and
↓
pushbuttons to view entire list. Option switch
settings can not be changed through the software. For more information about the
internal option switches, see “Internal Option Switches” later in this chapter.
To display the Option Switches screen:
From the Main Menu choose Diagnostics
From the Diagnostics menu choose Option Switches
To use the Option Switches screen:
This is a view only screen
Use the
↑
and
↓
pushbuttons to move up and down
Press
MENU
to return to the Diagnostics menu
Press
RUN
to return to the Run screen
#4 DOUBLE RANGE OFF
#5 AUTORANGE OFF
#6 LOCK OFF
#7 SPARE OFF
#8 FACTORY SET OFF
Option Switch Status Screen
OPTION SWITCHES:
>#1 REMOTE ON
#2 RS-232 ON
#3 Z/SPAN VALVE OFF
To Next Page
