Chapter 3 Operation
3-51
Min and Max Chamber Temperature Limits
. The Min Chamber
Temperature limit screen, shown below, is accessible only when the instrument is in the
service mode. It is used to change the min chamber temperature alarm limit. The min
and max Chamber Temperature screens function the same way.
To display the Min or Max Chamber Temperature limit screen (service mode on):
From the Main Menu choose Alarm
From the Alarm menu choose Chamber Temperature
From the Chamber Temperature menu choose Min or Max
To use the Min or Max Chamber Temperature limit screen (service mode on):
Use the
↑
and
↓
pushbuttons to increment/decrement the value
Press
ENTER
to accept the change
Press
MENU
to return to the Chamber Temperature menu
Press
RUN
to return to the Run screen
Set Min Chamber Temperature Screen
