Chapter 3 Operation
3-14
Custom Range Screen. The Custom Range screen, shown below, is used to define
the custom range.
The first line of the display shows the current custom range. The second line of the
display is used to set the range. To use the custom fullscale range, be sure to select C1,
C2, or C3 in the CO Range screen. See “CO Range” above for more information.
To display the Custom Range screen:
From the Main Menu choose Range
From the Range menu choose Set Custom Ranges
From the Set Custom Range menu choose C1, C2, or C3
To use the Custom Range screen:
Use the
↑
and
↓
pushbutton to increment and decrement each digit
Use the
←
and
→
pushbutton to move the cursor left and right
Press
ENTER
to accept the custom range
Press
MENU
to return to the Set Custom Ranges menu
Press
RUN
to return to the run screen
Set Custom Range 1 Screen
