Chapter 13 – Guideline Menu
91
13.2. Using identical curve guidelines
Some fields are not rectangular and have a curved or shaped boundary.
For these, identical curves may be the best option for guidelines. This
can be useful for steering the boundary of a field and using this
guideline for future operations.
Identical curves allows the operator to set a curved guideline and the
system will create equidistant guidelines across the field, based on a
swath width.
1. Position the vehicle.
2.
Select / Guidelines Menu / Change Guidance Mode,
if necessary, to choose Identical Curves .
3.
Select Create New Identical Curve .
4. Select GUIDELINE NAME.
5. Enter a name, if desired, and confirm. Confirm the new guideline.
6.
Drive to the start of the swath. Select Set ‘A’ Point .
7. Drive along the curved swath. A black line will appear behind the
vehicle on the map to indicate the curve that is being recorded.
Note: If required, recording the guideline can be paused.
8.
At the end of the curved swath, select to indicate the end of the
curve recording.
13.3. Using center pivot guidelines
Some fields are best worked in a circular shape. This setting allows the
operator to create guidelines around a center pivot point.
1. Position the vehicle.
