4.4. Setting up map options
24
Alarm audio
Enables sounds when an alarm is triggered.
System 150 file transfers
Enables the following System 150 (GX-45) files to be imported and
exported: AB lines, Pivots, Curves, Optimal lines, Project lines and
Field boundaries.
System 150 file transfers allow the operator to export files in a format
that matches Topcon’s System 110/150 system and import files that
were exported from System 110/150.
Enabling this option displays the System 150 icon at the base of
the Inventory Manager on the Operation screen (refer to
Inventory Manager, page 107).
Automatic steering status window
Displays a Steering Status window when the Auto Steer Engage
button is selected on the Operation screen if the steering is
unable to engage. The Steering Status window displays issues that
may be preventing the steering from engaging. If Auto Open and
Close is selected, the Steering Status window will automatically close
once any issues preventing the steering from engaging have been
resolved.
Note: The Steering Status window may still be displayed via the
Steering Options Menu / Auto Steer Status (see page 95) if this
setting is disabled.
4.4. Setting up map options
Sets how maps work on the Operation screen.
To set up the maps:
1.
Select User / Map .
The following options are available:
