7.4. Setting up section control
50
l Inline Offset: Measures the off-center offset of the implement
relative to the hitch point. Enter a positive number if the
implement is shifted to the right and a negative number if it is
shifted to the left.
l Trailer Offset: Measures the distance between the trailer hitch
point and the trailer wheels.
l Trailer Wheels Offset: Measures the distance between the
implement hitch point and the trailer wheels.
7.4. Setting up section control
To set up section control:
1.
Select Implement / Section Control / Sections .
2. Select SECTIONS and use plus or minus to set the number of
sections, then confirm.
3. To set the section width for all sections, select Width next to All.
4. Enter the section width for all sections and confirm.
5. To set individual widths for sections, select the width next to a
section, enter the width and confirm.
6. Repeat for each section.
7.4.1. Setting timing
These settings set the response times for the sections when switched
on or off. It is important to accurately calculate the response times to
avoid overlaps or gaps in product application.
To calculate the response times:
1. Ensure the implement is ready to begin product application.
2. Use a stop watch to time the delay between switching a section on
and the application of product. This is the ONTIME.
3. When the section is switched off, time the delay between
switching it off and the product ceasing to flow. This is the OFF
TIME.
To set the response times:
