Chapter 9 – Operation Basics
61
HDOP < 1.0
HDOP between 1.0 and 4.0
HDOP > 4
GPS invalid 0
Good accuracy
Average accuracy
Poor accuracy
No signal
The HRMS (Horizontal Root Means Squared) calculates an average
horizontal position from the source information from the satellites.
9.5. Viewing system diagnostics
To view diagnostic information:
1.
Select System Diagnostics from the Navigation window
. Memory usage and trouble codes display.
9.6. Viewing job information
To view job information:
1.
Select Job Information from the Navigation window
.
This shows overall information on the job’s progress.
2. To view other information or to take notes, select the following
tabs.
Job Statistics
Job Settings
