6.5. Selecting the vehicle antenna
46
6.5. Selecting the vehicle antenna
Sets whether the GPS receiver has an internal (built into the receiver)
or external antenna. Internal antenna is set as default.
To set the antenna type:
1.
Select Vehicle / Antenna .
If External is selected, the measurements for the location of this
antenna must be entered:
Forward offset to AGI-4 (or AGI-3)
Enter the distance forward from the center of the AGI-4 to the center
of the antenna (use a negative number if the antenna is behind).
Right offset to AGI-4 (or AGI-3)
Enter the distance to the right from center of AGI to center of antenna
(use negative number if antenna is to the left of the AGI).
Height
Enter the height of the antenna above the ground.
