4.2. Setting up the lightbar
22
Area units
l ha (hectare)
l ac (acre)
l Default: Selects the default setting appropriate for the selected
Units
Liquid product volume units
l Litres l Gallons
l Cubic meters l Cubic feet
l Tonnes l Pounds
Application rate increment type
l Fixed rate
l Percentage of Preset 1
This option changes the behavior when the operator presses the
up/down buttons to change the requested product application rate.
These can either change by a fixed rate or by a percentage of the rate
set for RATE PRESET1.
Application rate units
l L/ha l gal/ha
l L/100m l gal/100yd
l L/100m
2
l gal/kft
2
4.2. Setting up the lightbar
During operations, the virtual lightbar on the top of the guidance
screen can show how far the vehicle is deviating from the set
guideline.
To set up the lightbar:
1.
Select User / Lightbar .
The following options are available:
