5.4. Setting up flag points
38
Alarm Description
Reverse
station
Informational alarm triggered when the operator’s seat is
rotated by 180 degrees (only applicable for tractors with
dual driving stations).
Steering
disengage
(visual)
Triggered when the steering has been disengaged. This
may be due to losing satellites, losing the guideline or
manually turning the steering wheel.
Steering
engage
(visual)
The Steering Engage/Disengage alarms cannot be
silenced for safety reasons, however, the visual
component of the alarm can be suppressed if desired.
Steering
profile
mismatch
The parameters in the selected vehicle profile do not
match the vehicle configuration in the steering
subsystem. Select the correct vehicle profile for this
vehicle.
Steering
restart
needed
Triggered if the steering subsystem needs to be power
cycled. Occurs for some types of steering subsystem
after calibration.
Steering
unable to
engage
The steering status popup which appears when steering
cannot be engaged as requested can be suppressed. If the
engage button is pressed this auto clearing alarm is
shown to indicate the requested could not be completed.
5.4. Setting up flag points
Flag points show obstacles or other land features for a field on the
Operation screen. Flag points are set during operation by driving to
the flag point location. Refer to Setting flag points, page 83.
Flag point symbols and names can be defined in the Setup screen.
To change flag point preset symbols and names:
1.
Select System / Flag Points .
2. Select the flag having its symbol or name changed.
