2.3.1. Implement color indicators
This indicates the position and direction of the vehicle and its
implement. The implement color indicates product application status:
l Red: Section is off.
l Blue: Section is inhibited (on and not flowing, typically due to low
speed or pressure).
l Yellow: Section is on and not flowing intentionally (typically due
to auto-section control stopping the flow).
l Green: Section is on and flowing.
l Orange: Section is on and not flowing unintentionally or OFF but
still flowing unintentionally (typically due to a delay in the time it
takes for the flow to start up).
2.4. Icon descriptions
2.4.1. Guidance toolbar
Field menu, 77
Job menu, 85
Guideline menu, 89
Steering options menu, 95
Nudge menu, 103
2.4.2. Menu icons
Field menu
Field menu, 77
Select field, 77
To Next Page
