Chapter 6 – Vehicle Setup
43
are appropriate, select Other and go to Customizing a vehicle, page
43.
Note: Select to go up one level to the parent folder.
3. Select the vehicle model and confirm.
4. To change the name, select VEHICLE NAME, enter the name and
confirm.
5. Confirm the new vehicle. The Vehicle Geometry screen displays.
6. Go to Setting the vehicle geometry, page 43.
6.2.1. Customizing a vehicle
When Other is chosen from the Vehicle Template screen, generic
vehicle templates are displayed that hold basic vehicle information and
steering parameters.
1. Select Other. A list of steering controllers displays:
l ACU-1: Autosteering Control Unit
l AES-25: Accurate Electric Steering
l AF: AutoFarm
®
valve block
l RST: Raven SmarTrax
™
valve
l Other: Any other steering controller
2. Select from the list and confirm. A range of generic vehicle
templates displays.
3. Use the arrows to select the template shape most like your vehicle
and confirm.
4. To change the name, select VEHICLE NAME, enter the name and
confirm.
5. Confirm the new vehicle. The Vehicle Geometry screen displays.
6. Go to Setting the vehicle geometry, page 43.
6.3. Setting the vehicle geometry
Sets the vehicle measurements so that guidance can work accurately.
Note: Measure the vehicle dimensions as accurately as possible. The
recommended tolerance is +/- 5 cm.
