Chapter 4 – Regional and User Settings
25
Point of focus
l Vehicle: Places the vehicle at the center of the screen.
l Implement: Places the implement at the center of the screen.
Map panning
Allows the screen to move around in a map when the user slides a
finger across the screen.
Enabling this option places the map panning icon beside the Toggle
Map View and Map Layers at the top of the Operation screen. Touching
this icon re-centers a panned map to the current location of the vehicle.
Highlight loaded coverage
After loading an existing job, shows previously completed and loaded
coverage in a different color from the newly created coverage.
Previously covered areas are shaded yellow if this has been
enabled and past job information has been recorded.
New coverage is shaded green. If this option is not enabled,
both the previous coverage (from the loaded job) and the
newly recorded coverage are shown in the same green color.
Pause boundary recording with master
If the master switch is turned off while a boundary is being recorded,
the boundary recording is paused. Turning the master switch back on
resumes the boundary recording.
This may be useful to automatically pause boundary recording if
product application is paused to maneuver in a tight corner or deviate
around an object.
Note that boundary recording may still be manually paused (refer to
Setting a new boundary, page 78).
Visual reference line length
Provides a display marker at the user prescribed distance in front of the
vehicle icon to help accurately acquire the wayline after a turn when
using manual guidance.
