Chapter 14 – Auto Steering
97
Error Display Actions Page
Steering controller
displays with red
Confirm controller is connected and
turned on.
Confirm that the correct steering
controller has been selected during
setup.
If using AES-25, power cycle the AES-
25, then turn wheel a ¼ turn to enable
steering.
45
Vehicle geometry
displays with red
Return to Setting the Vehicle Geometry
and reset dimensions correctly or re-
select the vehicle profile.
43
Vehicle profile
displays with red
Review which vehicle has been selected
and review geometry.
42-43
Steering calibrated
displays with red
Confirm calibrations have been done
for this vehicle. Drive to an open space
away from power lines and obstacles,
reboot and repeat calibrations.
67-70
Lockout The steering system has been put into a
transport mode (i.e. when driving on a
highway) so that the steering cannot be
inadvertently engaged.
Wayline available
displays with red
Drive closer to the wayline (guideline).
Confirm that guideline has been
created and selected.
89-91
Wayline
synchronized
Wayline (guideline)is not successfully
loaded. Confirm connection with
receiver and reload the wayline. Note
that it may take some time for the
wayline to be uploaded to the receiver,
particularly for large curves.
