8.1. Sense of rotation test of the electric motor
Close knife box door.
Remove all loose objects from the insertion shaft.
Set main switch to » ON«
The following display will appear:
Please open the lid
of the cutting
chamber and close it
again !
Please open the infeed device and close it again
Depending on the setting of the ’LID START’ button (arrow):
– LID START OFF (lamp off):
The knife makes a SINGLE CUT, cutting program P1 appears on the
display and the cutting material holder takes up the rear stop position.
– LID START ON (lamp on):
Cutting program P1 appears on the display, the knife operates until
the cutting material holder reaches the front stop position and swit-
ches over to ’return journey’.
The knife must rotate top down through the shaft!
If this is not the case:
Have two of the three phases of the supply line changed.
Note:
Phase changes may only be performed by a chartered electrician.
Trial run
02/2005 123842-GB Page 25
