4. General arrangement of the machine
1.
Cover of the removal chamber
2.
Door latch
3.
Knife box door with integrated removal chamber
4.
Control panel
5.
Loading door
6.
Additional control panel
7.
Feed cover
8.
Main switch (Emergency-shut down)
9.
Pneumatik-Wartungseinheit
1 2 3 4 5 6 7
8 9
General arrangement of the machine
Page 12 02/2005 123842-GB
