18.4. Calibration routine
Press the Service key to access the service menu.
Select the CALIBRATION ROUTINE parameter.
Use the program function keys to enter P2, P5, P4, and P6 user
code after each other. In the process, press the Shift key and keep
it pressed.
Attach a cuttable and firm measuring object to the gripper hook.
Use the Feed forward and Feed backward keys to move the feed unit
to the front most position.
Caution:
The feed unit must not be moved into the dynamic feed
system DVS !
Press the Start key to start the calibration routine.
The completion of the routine will be indicated by OK on the display.
Service Menu
Page 84 02/2005 123842-GB
