11.16. Operating mode single knife LS
Cutting with empty cuts
This section describes the possibility of cutting up a previously defined
number of slices to a group of slices by including empty cuts and
depositing them at intervals.
s16 escalopes
CUTTING THICKNESS
15,0 (0,5-250)
*
Enter program parameters
The desired operating mode LS is set via the two lower arrow keys.
The following program parameters can be set:
Alteration of set values is only possible prior to the first cut!
The different cutting parameters can be invoked in succession according
to the following scheme by means of the program-content key "ARROW
UP".
The respectively displayed cutting parameter can be altered via the edit
key "+ / -".
Refer to section 11.8. for explanatory notes to the individual parameters.
s16 escalopes
CUTTING THICKNESS
14 mm (0,5-250)
*
s16 escalopes
Length range
100 % (0-100)
*
Method of operation of the control
Page 50 02/2005 123842-GB
