10. Accessory
10.1. Conveyor belt in the insertion shaft
Set the main switch to position OFF, and remove the mains plug from
the power outlet.
Dismounting the holding appliance:
Open filling cover to the limit stop
Lift retainer away from the chamber wall slightly and pull back.
Disassemble the conveyor belt
Remove feed cover upwards.
Loosen hexagon nut several turns using the provided ring spanner
and dismantle the cutting material holder.
Loosen both star handles and unscrew completely.
Lift the front conveyor belt (arrow) out of the machine.
Lift the rear conveyor belt (arrow) out of the machine.
Accessory
Page 30 02/2005 123842-GB
