3.3. Technical data
PUMA-CE electronic 700 E 700 EB 1100 E 1100 EB 700 E
-HS
700 EB
-HS
1100 E
-HS
1100 EB
-HS
Type ( refer to chapter 3.1.) -194 0 -194 3 -195 0 -195 3 -394 0 -394 3 -395 0 -395 3
length x width x height refer to chapter 3.2.
weight 285 kg 305 kg 305 kg 325 kg 285 kg 305 kg 305 kg 325 kg
maximum feed length 700 mm 1100 mm 700 mm 1100 mm
maximum cross section of
product to be cut
220 x 240 mm
cut-off length
- with single knife
- with double knife
- with single knife ’RS’
- with single knife ’LS’
0,5 - 35 mm
continuously adjustable
0,5 - 25 mm continuously adjustable
0,5 - 250 mm* continuously adjustable
0,5 - 15 mm continuously adjustable
0,5 - 25 mm continuously adjustable
0,5 - 15 mm continuously adjustable
0,5 - 250 mm* continuously
adjustable
0,5 - 15 mm continuously adjustable
cuts per minute
- with single knife
- with double knife
200
400
280
560
conveyor speed - - - 1,5 - 30
m / min.
- - - 1,5 - 30
m / min.
- - - 1,5 - 30
m / min.
- - - 1,5 - 30
m / min.
operating voltage refer to type plate
connected load 3,4 kW 3,5 kW 3,4 kW 3,5 kW 3,4 kW 3,5 kW 3,4 kW 3,5 kW
equivalent continuous noise
level
< 75 dB (Ain idle operation)
min. temperature
of product
-4° Cel.
other temperatures to order
permissible ambient
temperature
0 to 40° Cel.
other temperatures to order
* In case of cut-off lengths exceeding 35 mm bzw. 25mm, the knife is rotated
inter-
mittently. The machine should not be operated in this operating mode
permanently. The thermal motor switch could switch the machine off
for a short time.
3.4. Range of operation and intended application
Use TREIF PUMA-CE ’electronic’ only to cut foodstuffs, such as meat,
sausage, cheese or fish. The temperature of the product must not drop
below -4° Celsius.
Use of the machine exceeding the above range is considered to be
unintended.
Thus, wood must not be cut on this machine, for example !
The producer shall not be held liable for damage occurring from uninten-
ded use; the risk shall be borne by the user exclusively.
Intended use shall also include the observation of these operating
instructions and the adherence to the maintenance instructions.
ATTENTION: Serious damages to the knife and machine may
occur when cutting materials that are too hard or strongly
frozen, or as a result of foreign matter in the cutting channel!
This may also result in dangers to persons!
Dimensions and technical data
Page 10 02/2005 123842-GB
