Refer to chapter 11.15.: Operating mode single knife ’RS’
Cutting within several cutting ranges
Alter cutting parameters
Alteration of set values is only possible prior to the first cut!
The different cutting parameters can be invoked in succession according
to the following scheme by means of the program-content key "ARROW
UP/ DOWN". The respectively displayed cutting parameter can be alte-
red via the edit key "+ / -".
Refer to section 11.8. for explanatory notes to the individual parameters.
s4 cutlets
cutting regions
3 piece (1-10)
*
s4 cutlets
CUTTING THICKNESS 1/3
10 mm (0,5-250)
*
s4 cutlets
Length range 1/3
30 % (0-100)
*
Method of operation of the control
02/2005 123842-GB Page 47
