Failover between 3 meters - 100 meters: Purchase ber Active Optical Cable (AOC) or QSFP+ SR4 transceiver module
from Trellix or QSFP+ SR4 transceiver module from an external source.
Failover between 100 meters - 300 meters: Purchase QSFP+ SR4 transceivers from Trellix or QSFP+ SR4 transceiver from
an external source.
Failover above 300 meters: Purchase QSFP+ LR4 transceivers from Trellix or QSFP+ LR4 transceivers from an external
source.
Steps:
1. Plug the cable(s) appropriate for use with your QSFP+ module into port G0/1 (NS9100, NS9200) or G1/1 and G1/2 (NS9300)
of the active NS-series Sensor.
2. Connect the other end of the cable(s) into port G0/1 (NS9100, NS9200) or G1/1 and G1/2 (NS9300) of the standby NS-series
Sensor.
:
Turning the Sensor on and o
Do not attempt to turn on the Sensor until you have installed the Sensor in a rack and made all the necessary network
connections.
Steps:
1. Connect the power cable to the Sensor power supply.
2. Connect the power cable to a power source.
If you are installing a redundant power supply, you should install it as described in Install a new power supply section.
For true redundant operation with the redundant power supply,Trellix recommends that you plug each supply into a
dierent power circuit.
The Sensor has no power switch. The Sensor turns on as soon as one of its power cables is connected to a power
source.Trellix recommends that you use the shutdownCLI command to halt the Sensor before turning it o. For more
information on CLI commands, see the CLI commands section in Trellix Intrusion Prevention System Product Guide for specic
Sensor software version you are running.
:
