RJ-45 10/100/1000 Mbps ethernet monitoring ports — Enables you to monitor eight SPAN ports, four segments in-line,
or a combination
External USB ports — Use these in troubleshooting situations for system recovery purposes. You need to restart the
Sensor through the USB storage device.
RJ-45 10/100/1000 Management port — Use for communication with the Manager server. You can assign an IP address
to this port during installation.
RJ-45 10/100/1000 Response port — When you operate this port in SPAN or tap mode, it enables you to inject response
packets back through a switch or a router.
Power Supply — Power supply is included with an NS5x00 Sensor. The supply uses a standard IEC port (IEC320-C13).
Trellix provides a standard, 2 m NEMA 5-15P (US) power cable (3 wire). International customers must procure a country-
appropriate power cable.
The NS-series Sensor does not have internal taps; you must use it with a third-party external tap to run it in tapped mode.
:
Sensor LEDs
The front and rear panel LEDs provide status information for the health of the Sensor and the activity on its ports. The following
table describes the NS-series LEDs.
Front panel LEDs
LED Status Description
Status Green
Amber
Sensor is operating in good
health.
Sensor is booting up. It also
indicates system bad health.
Fan Green
Amber
All the fans are operating.
One or more fans are not
working.
Temp Green
Amber
Inlet air temperature measured
inside the chassis is normal.
(Chassis temperature OK)
Inlet air temperature measured
inside the chassis is too high.
(Chassis temperature too hot)
