The faceplate panel must remain in place unless a power supply is in the power supply slot. Do not operate the Sensor
without the faceplate panel in place.
3. Place the power supply in the slot with the cable outlet facing front and on the left side of the faceplate.
4. Slide in the power supply until it makes contact with the backplane, then push rmly to mate the connectors solidly with the
backplane.
For true redundant operation with the optional redundant power supply, Trellix recommends that you plug each supply
into a dierent power circuit. For optimal protection, use uninterruptible power sources.
:
Remove the power supply
Perform this task if you want to remove the power supply to the Sensor.
Steps:
1. Unplug the power cable from its power source and remove the power cable from the power supply.
2. Push the release latch sideways toward the handle.
3. Center the handle of the power supply and pull on it to remove the power supply.
4. Use faceplate panels to protect unused slots from dust and to reduce electromagnetic radiation.
5. Replace the mounting bracket.
To avoid data interruption, do not turn o both power supplies on an in-line Sensor; or else the Sensor shuts down and
all Sensor function stops. Turn o only the power supply that you are replacing.
To remove all power from the Sensor, unplug all power cords.
:
NS7x00 Network Interface modules
The NS7x00 Sensors support the 4-port, 6-port, and 8-port Network Interface modules. These modules need to be installed in
the respective slots on the Sensor. The supported modules are:
