connect directly to the console for initial conguration; you cannot congure the Sensor remotely. Terminal servers are
provided for console access. Required settings for HyperTerminal are listed below:
Name Setting
Baud rate 115200
Number of bits 8
Parity None
Stop bits 1
Flow control None
3. Turn on the Sensor.
:
Connect the cable to the Response port
While operating in tap or SPAN mode, the Sensor uses its Response port to respond to attacks. When deployed in tap mode, the
Sensor does not inject response packets through the tap but uses the Response port.
Steps:
1. Plug a Cat-5e Ethernet cable into the Response port.This port is labeled R1 on the Sensor rear panel.
2. Connect the other end of the cable to the network device such as a hub, switch, or router, through which you want the
Sensor to respond to attacks.
:
Connect the cable to the Management port
The Sensor communicates with the Manager using the Management port.
Steps:
1. Plug a Category 5e or 6a Ethernet cable into the Management port.This port is labeled MGMT in the front panel of the
NS3x00 Sensor.
