Trellix NS Series - About Connecting Cables to the Monitoring Ports; How to Use Peer Ports

•
•
•
•
•
•
•
•
To isolate and protect your management trac, Trellix strongly recommends you to use a separate, dedicated
management subnet to interconnect the Sensors and the Manager.
:
About connecting cables to the Monitoring ports
Connect to network devices that will send trac to the Sensor monitoring ports. You can deploy Sensors in the following
operating modes:
Inline Fail Open
Inline Fail Open – Active
Inline Fail Open – Passive
Inline Fail Closed
SPAN or Hub
Tap
:
How to use peer ports
You must use two peer monitoring ports of the Sensor to deploy it full-duplex mode. On the Sensor, the numbered ports are
internally wired in pairs to accommodate the trac.
On NS5100 and NS5200 Sensors, G0, G1, and G2 indicate xed port slots.
Since monitoring ports are internally wired, when you disable one of the ports in a pair, the corresponding port is
also disabled.
The following ethernet ports are coupled and must be used together.
Port Pairs Sensor
G0/1 and G0/2 NS5200/NS5100
G1/1 and G1/2 NS5200/NS5100
G1/3 and G1/4 NS5200/NS5100
| NS5x00 Sensors6
