The NS3100/NS3200 Sensor model
Sensor front panel
1. Console port (1)
2. RJ-45 10/100/1000 Management port (MGMT) (1)
3. RJ-45 10/100/1000 Response port (R1) (1)
4. USB port (1)
5. RJ-45 10/100/1000 Mbps Ethernet Monitoring ports (8)
Sensor rear panel
1. Power supply inlet (1)
2. Fan units (3)
The direction of airow in all the Sensors is from front to back. Cold air enters through the front of the chassis.
The following table gives the details of the supported ports.
Ports
NS3100/NS3200
Fixed RJ-45 ports (internal fail-open)
8 (10/100/1000 Mbps)
Console port 1
Dedicated Response ports (RJ-45) 1 (10/100/1000 Mbps)
