Trellix NS Series - Page 82

•
•
Sensor Specics NS9500
Dimensions 17 ¼" (W) x 29 1/16" (D) x 1 ¾" (H)
Weight 28.55 lbs
Storage 2 x 240 GB M.2 drive
System Heat Dissipation
Maximum BTU 2038 BTU/hr
Typical BTU 1790 BTU
Maximum Power Consumption 598 W
Typical Power Consumption 525 W
Redundant Power Supply Yes
Power 100 - 240 VAC (50 - 60 Hz)
DC Power Supply Installing DC power supply is optional.
Maximum Power Consumption: 598 W
Maximum BTU: 2038 BTU/hr
Power Supply Unit:
Input V: - 40 to -72 V
Input A: 12.45 A
Temperature Operating: 0° to 35° C , Non-operating: - 40° to 70° C
Relative humidity (non-condensing) Operational: 10% to 90%, Non-operational: 5% to
95%
Altitude 0 to 10,000 feet
Safety Certication UL 60950-1 (USA); CSA 22.1.No. 60950-1 (Canada);
EN 60950-1 (Europe); CNS 14336-1 (Taiwan), GB
Trellix Intrusion Prevention System NS-series Sensor Product Guide
| NS9500 Sensors1
82
