The fan units and power supplies of NS9100, NS9200, and NS9300 are eld replaceable and hot swappable.
The following table gives the details of the supported ports.
Ports
NS9100/NS9200 NS9300
Fixed Gigabit Ethernet—Copper
Ports
(internal fail-open)
8 16
Fixed 40-Gigabit Ethernet 2 4 (used as interconnect ports
between NS9300P and NS9300S )
Network I/O Slots 2 4
Network I/O Modules (four
options)
8 port (SFP+/SFP) 10 GigE/1 GigE
6 port RJ-45 10/100/100 Mbps
2 port (QSFP+) 40 GigE
4 port (QSFP+) 40 GigE
8 port (SFP+/SFP) 10 GigE/1 GigE
6 port RJ-45 10/100/100 Mbps
2 port (QSFP+) 40 GigE
4 port (QSFP+) 40 GigE
10 Gigabit Ethernet Modular up to 16 Modular up to 32
40-Gigabit Ethernet Modular up to 8 Modular up to 16
10/100/100 Mbps Modular up to 12 Modular up to 24
Dedicated Response Ports (RJ45) 1 (10G/1G/100M) 1 (10G/1G/100M) on NS9300S
Dedicated Management Ports
(RJ45)
1 (10G/1G/100M) 1 (10G/1G/100M) on NS9300P
Dedicated Auxillary Port (RJ45) 1 (10G/1G/100M) 2 (10G/1G/100M)
USB ports 2 4
RJ-45 10/100/1000 Management port, which is used for communication with the Manager server. You can assign an IP
address to this port during installation. These ports have built-in fail-open function.
Console port, which you use to set up and congure the Sensor using the CLI.
