AWC7813 motion controller user manual
5.2 Basic steps of using the laser machine to cut graphs
1) Install the LaserCAD software, see the software operation manual for
details;
2) According to the existing machine, set the machine zero position, page zero
position, and relative graphic position of the laser head in the software,
please refer to the software operation manual for details;
3) Draw the picture in the software or import the picture into the software;
4) Set the working mode, power and speed in the software layer parameters;
5) Turn on the machine normally, turn on the water tank, fan, etc.;
6) Select the communication method and transfer the file to the control card;
7) Move the laser head to estimate the approximate position of the cut image,
and press the 【Origin】 key on the panel;
8) Press the 【Box】 key to check the size and position of the figure, and place
the material;
9) Press the 【Start】 key and the machine will start cutting. If you find that
the cutting effect is not good, press the 【Pause】 key to adjust the power
and speed on the panel, please refer to 3.9.2 Modify the speed of the file
being processed、3.10.2 Modify the power of the file being processed; Or
press the【Stop】key, click the file name, and adjust the【layer parameters】
of the processing file. For details, see3.7.2 layer parameters of processing
files; Or adjust【Motion Parameters】and 【Axis Parameters】, please refer
to 3.14 Motion Parameters Settings、3.16.1 Axis parameters(take X axis as
an example).
