AWC7813 motion controller user manual
Figure3-2-3 Menu
In the Figure3-1-2 Main interface 2 interface, click the 【Menu】 button to enter
the Menu interface, which includes 【UDisk Files】,【Origin manage】,【Motion
Parameters Settings】,【Common parameters Settings】,【Manufacturer Parameters
Settings】,【Network Settings】,【Language】,【System Version】eight functions. For
details, please refer to 3.12-3.19.
3.2.4 More
Figure3-2-4 More
In the Figure3-1-2 Main interface 2, click the【More】button, Can enter【Ins】,【Outs】,
【Cut Box】,【Reset】,【Move】,【Other】interface. For details, please refer to 3.20-3.25.
3.2.5 Laser
Figure3-2-5 Laser
In the Figure3-1-1 Main interface 1, press and hold【Laser】to turn on laser, release
To Next Page
