3.15.2.1 AutoFocus Distance(mm)
It refers to the distance between the laser head and the surface of the material.
The wrong focus distance will affect the cutting and engraving effect. After setting,
turn on the 【Z-axis for Autofocus】 function, and then click 【More】→【Others】
→【Z Autofocus】 to complete focusing. For details, please refer to 3.16.6 Function
Configuration、3.25.1 Run Z AutoFocus function.
3.15.2.2 KeyMove’Speed(mm/s)
Except in the standby state, you can directly modify the【KeyMove
’
Speed(mm/s)】
in the speed area in the Figure3-1-3 Main interface area division, and you can also enter
the Menu interface to modify. After 【 KeyMove
’
Speed(mm/s) 】 is modified in
【Common parameters】 interface, the key movement speed of the main interface
will change accordingly.
【KeyMove
’
Speed(mm/s)】 refers to the axis movement speed when pressing
the arrow key on the panel. The maximum value of【KeyMove
’
Speed(mm/s)】 cannot
exceed the smaller value of 【Max Speed】of X and Y axis parameters. If the 【Max
Speed】 of the X axis is 500 and the 【Max Speed】of the Y axis is 600, then the
【 KeyMove
’
Speed(mm/s) 】 <=500. For related content, please refer to 3.9 Speed
Display Area.
3.15.2.3 RunBox’Speed(mm/s)
The speed at which the laser head makes a circle around the outer frame of the
graph when it does not laser. The maximum value cannot exceed the small value of
【Max Speed】of X and Y axis parameters. If the【Max Speed】of the X-axis is 500 and
the【Max Speed】of the Y-axis is 600, the【RunBox’Speed(mm/s)】<=500. Please refer
to the definition of RunBox’Speed(mm/s) 3.2.6 Box.
