AWC7813 motion controller user manual
WWW.SZTROCEN.COM
9
209mm
125mm
135mm
1.6 Appearance and size of wiring board
Figure1-6-1 Appearance display of wiring board
Figure1-6-2 Wiring board size diagram
195mm
