AWC7813 motion controller user manual
3.9 Speed display area
3.9.1 Quickly modify the key move speed in standby mode
When the machine is idle, the speed area displays 【 KeyMove’Speed 】 in
Figure3-1-3 Main interface area division interface, at this time, you can click the numeric
key after 【 Speed 】 to modify. After the speed is modified in this interface, the
【KeyMove’Speed】 in 【Common Parameters】 will also change accordingly. For
details, please refer to 3.15.2.2 KeyMove’Speed.
Figure3-9-1 Quickly modify the key move speed
3.9.2 Modify the speed of the file being processed
When the machine is working, the speed area displays the working speed of the
laser head in Figure3-1-3 Main interface area division interface, that is the speed of
processing files. After clicking the【Pause】button, this value can be modified. The
modified value is only valid in the current job, and it will be restored to the value
before modification when the work of this file is completed.
