2.3 Mainboard interface description
2.3.1 U Disk interface
Copy the processing files to the mainboard and upgrade the mainboard via U
disk. For related content, see 3.12 U disk transfer files and mainboard upgrade.
Figure2-3-1 U Disk interface
2.3.2 USB interface
The USB interface is the interface that the mainboard and PC access through the
USB cable. The USB cable and USB extension cable for details please refer to 1.4.2
List of accessories.
Figure 2-3-2-1 USB interface (front view)
USB cable
