AWC7813 motion controller user manual
3.15.1.3 Go Back Position
【Current Position】: laser head will stay at where task finished;
【Current Origin】: go back to Origin point after finishing work;
【Zero Coord】: laser head goes back to machine zero point since
all finished.
3.15.1.4 Count Mode
【Count per work】: Count plus one after processing all graphics in one format;
【Count per Light】: When the laser head emits light, it counts plus one;
【Single of Array】: The count of a solid line figure in the array is increased by
one after processing.
3.15.2 Common Parameters
In the Figure3-1-2 Main interface 2 interface, click 【 Menu 】 → 【 Common
Parameters Settings】→【Common Parameters】 enter the interface.
Figure3-15-2 common Parameters
