AWC7813 motion controller user manual
WWW.SZTROCEN.COM
56
3.15.2.4 CutBox’Speed(mm/s)
The speed at which the laser head emits light and cuts the frame of the figure.
The maximum value cannot exceed the small value of【Max Speed】of X and Y axis
parameters. If the【Max Speed】of the X-axis is 500, and the【Max Speed】of the Y-axis
is 600, then the【CutBox’Speed(mm/s)】<=500. For related content, please refer to
3.22 Cut Box.
3.15.2.5 Blow Open Delay(s)
The time interval from when the machine starts to blow air until the laser head
emits light. Setting too large will affect the cutting efficiency, and it will pause for a
while before cutting.
3.15.2.6 Blow Close Delay(s)
The time interval from when the laser stop to when the blowing stops. Setting
too large will affect the cutting efficiency.
3.15.3 Axis Speed Parameters
In the Figure3-1-2 Main interface 2 interface, click 【 Menu 】 → 【 Common
Parameters Settings】→【Axis Speed Parameters】 enter the interface.
