content 2.2.2 Universal input port；
2) In Figure3-1-2 Main interface 2 interface, click the button behind 【Menu】
→【Manufacturer Parameters Settings】→【IO Parameters】→【Foot Switch】
to select 【Enable】.
3.16.3.2 Open Protection
During the working period of the laser cutting machine, in order to prevent the
deflection of the laser beam from hurting people, the upper protective cover of the
laser machine needs to be lowered. When the lid of the laser is not closed, and the
function of 【Open Protection】 is turned on at this time, it will prompt "Opened
Protected!" and the machine stops working. Ensure that the effective level when the
hardware is connected to work is the same as the corresponding 【input IO effective
level】 configuration in the panel, otherwise the " Opened Protected!" prompt will
appear. The modification steps are as follows:
1) Connect the corresponding hardware, the signal pin of the mainboard
corresponding to the open protection is IN1, please refer to the relevant
wiring content 2.2.2 Universal input port;
2) Ensure that the effective level when the hardware is connected to work is
the same as the configuration of the [input IO effective level] in the panel.
For details, see 3.20 Input Test；
3) In Figure3-1-2 Main interface 2 interface, click the button after 【Menu】→
【 Manufacturer Parameters Settings 】 → 【 IO Parameters 】 → 【 Open
Protection】 to select 【Enable】.
3.16.3.3 Input Valid Level
【Input valid level】 means to set input IO to 【Low-level】 or 【High-level】.
Ensure that the effective level when the hardware is connected to work is the same
