3.13.1 Set origin coordinates
1) In the Figure3-1-2 Main interface 2 interface, click【Menu】→【origin manage】
→【origin 1】;
2) If you know the coordinate value of a certain origin, directly enter the value
key after XY, and then click【Set Current position as the origin】to set it;
3) If the coordinate value of the origin is not clear, click the right direction
button to move the laser head to the desired origin and then click 【Move
head to the origin】to set it, and the other three origin are the same.
3.13.2 Move the laser head to the set origin
When the laser head position is not at the required origin
,
in the Figure3-1-2 Main
interface 2 interface, click【Menu】→【origin manage】→【origin 1】→【Move head
to the origin】to set it.
3.14 Motion Parameters Settings
【Motion parameters】are restricted by【Axis Parameters】 in 【Manufacturer
Parameters Settings 】 . If the user encounters a situation where the 【 Motion
Parameters】 cannot be adjusted, you need to adjust the 【Axis Parameters】 first,
such as 【Start Speed】, 【Max Speed】, 【Max Acc】. In the Figure3-1-2 Main interface
2 interface, click【Menu】→【Motion parameters Settings】 then enter the motion
parameters settings interface.
