AWC7813 motion controller user manual
In the Figure3-1-2 Main interface 2, after clicking the 【Reset】 button, the laser
head will move in the X-, Y- direction. When it touches the X-, Y- limit switches, the
laser head will stop and then move back for a certain distance. This distance is zero
offset distance. 【Zero offset(mm)】Please refer to 3.16.1.10 Zero Offset.
This function is to determine the zero position and establish a coordinate
system. If you do not reset, you may not return to the zero position or mistakenly
believe that the non-zero position is the zero point, and the cutting or engraving
graphics will exceed the【Range(mm)】. Please refer to the definition of【Range(mm)】
3.16.1.6 Range(mm). No matter what state the system is in, press this key to return
to the standby state and restart operation.
3.2.2 File
Figure3-2-2 File
In the Figure3-1-2 Main interface 2, Click the 【 File 】 button to enter the file
operation interface. This interface can browse the files stored in the board, and
perform operations, such as【Select】,【Data Check】,【Copy to UDisk】, and【Delete】
on the files. For related content, please refer to3.11 File operations.
3.2.3 Menu
