AWC7813 motion controller user manual
please increase the 【manufacturer parameters】 first, including 【Start Speed】,
【Max Acc】, and 【Max Speed】.
【Start speed】 refers to the starting speed of the laser head from stationary to
starting to move. It limits the【Start Speed】in【Motion Parameters】.【Start speed】
can't be too large, otherwise it is easy to shake when starting processing.
3.16.1.8 Max Acc
【Max Acc】 refers to the maximum speed change of the motion axis during
acceleration and deceleration. The 【Max Acc】 of the laser head defaults to the
smaller value of the X axis and Y axis 【Max Acc】. For example, the 【Max Acc】 of
the X axis is 500 and the 【Max Acc】 of the Y axis is 600. So 【Max Acc】 is 500. This
value limits the maximum value of 【Engrave Acc】 in 【Motion Parameters】. For
details, please see 3.14.1.5 Engrave Acc.
3.16.1.9 Max Speed
【Max Speed】 refers to the highest limit speed that the motion axis can bear.
The maximum value of 【Max Speed】=【Distance per pulse】*180, when it exceeds
this value, it will default to distance per pulse*180. This value limits the maximum
value of 【Space Speed】. For details, please see 3.14.1.1 Space Speed.
3.16.1.10 Zero Offset
The limit switch is not necessarily in the range, so it is necessary to adjust the
zero position. That is, the machine zero moves an offset distance along the X+
direction. When the machine is being reset, the laser head stops when it touches the
X-, Y- limit switches, and then walks back a certain distance, which is zero offset
distance.
